Invar 36 Spotlight

Invar 36[1], also known within the industry as Nilo 36[2], is a nickel-iron superalloy known for its low coefficient of thermal expansion. Containing 36% nickel, it maintains nearly constant dimensions as well as good strength and hardness over a wide range of temperatures. Invented in 1896 by Swiss physicist, Charles Edouard Guillaume, Invar was created as a low-cost solution to a meter once made of platinum and iridium. Guillaume’s work led to the discovery of a fairly inexpensive iron-nickel alloy—a steel-like material—that expands very little when heated. He named the alloy Invar because it was almost unchanging or "invariable.”

Invar 36 Success

One of our customers came to us specifically wanting to use INVAR 36 for a component requiring the near constant dimensions and long-term dimensional stability this alloy is known for. Due to confidentially agreements, we cannot name the customer but what we can tell you, is that like with many other projects, Signicast engineers rose to the challenge to not only cast Invar 36 successfully but completely exceeded the customers’ expectations—all while saving them money. Because after all, isn’t that the end goal? Create a quality component at the lowest total cost. 

Why did our customer need Invar 36? The slightest change in dimension or shape of their component could alter their end product—even though they were already in a temperature controlled room. A few degrees could alter the function of the part. They knew they needed to work with a material like Invar 36 but machining it from solid became costly.

How did Signicast help? We had never worked with Invar 36 in the past, but there has never been a challenge our engineers didn’t at least try to overcome. With some research and testing we came up with a casting material that actually performed as good or better than wrought and we were able to cast net-shape successfully. Not only did we add savings on final part cost because they didn’t have to machine the part, but our final part cost was actually cheaper than their original block of metal—prior to machining.

The end result? A very happy customer who saved tenfold and a new material added to our offerings.  

Invar 36 maintains nearly constant dimensions at temperatures below -150 degrees Celsius up to 260 degrees Celsius.

Who Should Use Invar 36?

Customers who are under strict temperature constraints will likely see the advantages of using Invar 36. Unfortunately, those who are currently machining from solid do not realize that casting net-shape is even an option. In today’s world, Invar 36 is often used in measuring devices, precision mechanical systems, laser components, thermostat rods, meters and components that transport liquefied gases—to name a few.

Invar Industry Applications

Invar can be used in a variety of applications within the aerospace, medical, and consumer electronics industries. But where superalloys with low CTE are really starting to outperform other metals is in technologies within the automotive industry. As autonomous vehicles rise in popularity, sensors, radars, and cameras become increasingly advanced and critical to the function of the car. LiDAR, an acronym for light detection and ranging, uses light waves from a laser to calculate how long it takes for the light to hit an object or surface and reflect back to the scanner—determining the distance of surrounding objects. An alloy with near constant dimensions and long-term dimensional stability, such as Invar 36, is extremely important in such intricate devices. Alternative alloys, like Kovar, with low CTE are also viable options for casting LiDAR sensors. Investment casting is a cost-effective solution compared to machining LiDAR parts from solid.

What are the Advantages of Invar 36? 

The most obvious advantage of Invar 36 is its ability to hold dimensions at cryogenic temperatures. Aside from that, Invar 36 looks and feels similar to steel. It also has outstanding weldability and machinability. Invar can also be created with customized chemistries to better meet the strength and hardness needs of customers.
